额定容量 KVA |
1级 |
2级 |
3级 |
短路阻抗
% |
|||
|
空载损耗
W |
负载损耗
W |
空载损耗
W |
负载损耗
W |
空载损耗
W |
负载损耗
W |
||
|
3150 |
1.7 |
20.7 |
2.0 |
20.7 |
2.4 |
21.9 |
7 |
|
4000 |
2.0 |
24.6 |
2.3 |
24.6 |
2.9 |
25.9 |
|
|
5000 |
2.4 |
28.2 |
2.8 |
28.2 |
3.5 |
29.7 |
|
|
6300 |
2.9 |
31.5 |
3.4 |
31.5 |
4.2 |
33.3 |
8
|
|
8000 |
4.0 |
34.6 |
4.7 |
34.6 |
5.8 |
36.5 |
|
|
10000 |
4.8 |
40.8 |
5.7 |
40.8 |
7.0 |
43.0 |
|
|
12500 |
5.5 |
48.4 |
6.5 |
48.4 |
8.0 |
51.1 |
|
|
16000 |
6.7 |
59.2 |
7.9 |
59.2 |
9.7 |
62.5 |
|
|
20000 |
7.9 |
71.6 |
9.4 |
71.6 |
11.5 |
75.5 |
|
|
25000 |
9.4 |
84.6 |
11.1 |
84.6 |
13.6 |
89.3 |
10
|
|
31500 |
11.1 |
100.8 |
13.1 |
100.8 |
16.2 |
106.4 |
|
